Water pumps are used for dewatering reasons decreasing the downtime from huge rain events. The common applications of these pumps include buildings, wells, boost application, circulation of hot water, sump pits, protection of fire systems, etc
Thus, this is all about water pumps which are frequently used in construction fields for removing surplus water as well as dewatering. Because of heavy rains, the flow of water can increase & water pumps let you supply the water rapidly to reduce downtime. These pumps are appropriate for applications like electric, hydraulic, gas-powered, and otherwise manual.
These pumps are vast addition to our life because they make possible a huge variety of industrial, agricultural and household tasks. But, the variety of water pumps in the marketplace is so adaptable and plentiful that selecting the correct pump appropriate for your requirements is challenging.
Material: The pump material should be weather-resistant for exposed uses.
Power: The power of the pump mainly includes horsepower & the flow rate.
Type of Fuel and Motor: The motor and fuel of the pump should be electric motor, gas, hydraulic, diesel, otherwise manual.
Head: The total head expulsion, otherwise utmost pump power, appropriate for the proposed application

Water pumps are classified into two types namely positive displacement and centrifugal. These pumps are mainly designed for supplying water from one location to another constantly.


Types of Pumps
Types of Pumps

Centrifugal Water Pump

Centrifugal pumps are designed with a rotating impeller which can be used for supplying the water into the pump and force the discharge flow. These pumps come in several types which includes trash, submersible, and standard models. By using these pumps, all types of liquids can be pumped with low-viscosity. And also these pumps work fine with thin fluids & gives high flow rates.

Considerations

These pumps are applicable in several applications like building as well as the water system. These pumps are used to provide water supplies for buildings and well-matched with pneumatic systems where the no-suction lift is necessary. The main purpose of these water pumps is to pump water from wells in homes & to increase water pressure in intake lines. Centrifugal pumps offer a nonstop pressure supply for fire guard systems, and they can supply like sump pumps in horizontal otherwise vertical configurations.
Centrifugal pumps are horizontal to numerous general problems. These may require liquid circulation to stop overheating which is caused by low supplies. These types of pumps must be prepared to work properly. As a head of the positive suction system is very less while selecting the pump, it can consequence to cavitations, a situation wherever air bubbles form close to the impeller, then leads to shock signals within the water pump. At last, wear of the impeller of the pump can be degenerated by delayed solids within the fluid.

Positive Displacement Water Pump

Positive displacement pumps supply a set amount of flow throughout the mechanical contraction and development of a stretchy diaphragm. These pumps are applicable in several industries that control high-viscosity fluids wherever responsive solids may be there. These are suggested for the applications wherever a combination of high pressure and low flow is required.

Considerations

Sometimes, these pumps are also called rotary pumps, and these are very competitive because of the fact that they remove air from the lines and therefore get rid of air leakage. These are also efficient while dealing with high-viscosity fluids. The main disadvantage of these pumps is that they need extremely little clearance among the revolving pump & the external edge of the unit. Consequently, the revolution must happen at extremely slow speeds. When the water pump is functioned at high speeds, then the fluid can ultimately decrease the efficiency of the pump.

If we reside in a city or town, we almost don’t think how the water is supplied to our residents every day. Small villages also frequently supply a set-up of pipes to transfer water for every home within the region. All we require to recognize is how to open the valve at the sink. Because the internal working is not visible, and the water supply is not dependent on the neighbors down the road. Every home has owned well and electromechanical system to draw the water from well and supply to the home. This article discusses an overview of the water pump and its working, types and their applications.

What is Water Pump?

The water pump can be defined as a pump which uses the principles like mechanical as well as hydraulic throughout a piping system and to make sufficient force for its future use. They have been approximately in one structure otherwise another because of early civilization. At present these pumps are utilized within a wide range of housing, farming, municipal, and manufacturing applications.

Water Pump Working Principle

The working principle of a water pump mainly depends upon the positive displacement principle as well as kinetic energy to push the water. These pumps use AC power otherwise DC power for energizing the motor of the water pump whereas others can be energized other kinds of drivers like gasoline engines otherwise diesel.
The water pump is a portable device and can be applied in several household applications. These pumps are used for pumping the huge amount of water from one place to another. The main purpose of a water pump is versatile. A quality pump which can be selected carefully may be perfect for draining water from a low flooded region, refilling the swimming pool, and bathtub, circulating pesticides otherwise fertilizers.
The collection of water pumps are very large, therefore, while selecting a strong and consistent one, one should think about the requirement.

These pumps are classified into different types namely lift pump, a force pump, axial pump, and radial piston-pump. From these pumps, lift and force pumps can operate manually otherwise with the help of an engine.


Types of Piston Pumps
Types of Piston Pumps

Lift Piston Pump

In this type of pump, the piston above stroke can draw fluid with the help of a control device which is named as valve into the below portion of the cylinder.
On the below stroke, fluid flows through control devices which are arranged in the piston into the higher portion of the cylinder. After that on the upstroke, fluid can be released from the higher portion of the cylinder through a spout.

Force Pump

In this type of pump, the piston pumps upstroke can draw fluid throughout an inlet valve to the cylinder (tube). On top of the downstroke, the fluid level can be discharged via an exit valve into the outlet tube.

Axial Piston Pump

This is pump is a PD (positive displacement) pump and it has several pistons within a circular array of a tube block. This block can be driven to turn its symmetry axis with an important shaft which is associated with the pumping pistons. These pumps can be used like an automotive air conditioning compressor, a separate pump, otherwise a hydraulic motor.

Radial Piston Pump

This pump is one kind of hydraulic pump, and the working pistons expand within a radial track symmetrically in the region of the drive shaft, in disparity in the direction of the axial piston pump.

The piston pump is strong, as well as simple devices. These pumps are made with a chamber, a piston, and a couple of control devices. These pumps function by flowing downward into the chamber, thus reducing the media within a hand pump. When the air pressure surpasses from the opening valve spring, then the reduced media can be sent throughout the open exit valve. As the piston is drawn back-up, then it releases the inlet valve & shuts the outlet valve, thus suction can be used to draw in extra media for compression. This article discusses an overview of piston-pump, working, types, etc


What is a Piston Pump?

The piston pump can be defined as it is a positive displacement pump. These pumps use a piston, diaphragm, otherwise plunger for moving liquids. These pumps use check valves as the input and output valves. The general piston-pump is a rotary pump which uses a wheel or revolving shaft for operating the piston.
The revolving component can be connected to a shaft from its center, and this shaft can be connected to the piston. When the revolving component twists, it runs the shaft as well as piston down to pull it back.

Piston Pump Working

The piston pump working is similar to PD pumps. Because they work with the help of the pumping mechanism force to increase the volume of the liquid. These pumps can use the power from power sources.
These pumps include more than one piston with a set of control devices. The duplex pump includes two pistons as well as two controlling devices. Similarly, a triplex pump includes three pistons as well as three controlling devices. It is very important to check the controlling devices on both sides to ensure that the flow of liquid direction at both sides is flowing or not.
These pumps are single otherwise double acting pumps. Double acting pumps involve two sets of controlling devices & liquid on both ends. This lets the pump to complete a pumping cycle by flowing in one direction to other. When the piston is taking in one direction, then it will exhaust at another side. This pump needs solo action versions for flowing in both directions for completing a cycle.

Advantages

The advantages of a piston pump mainly include the following.
  • The range of pressure is wide
  • Force can be managed without moving flow rate.
  • The rate of flow and Pressure changes has a small outcome on the act.
  • Skilled in moving of thick fluids, slurries, as well as abrasives with good control device design.

Disadvantages

The disadvantages of piston pump mainly include the following.
  • Maintenance cost, & operating is high usually bulky and heavy
  • They handle only lesser flow rates
  • Flow is Pulsating

Friday, September 27, 2019

Construction - Advantages and disadvantages of Globe valves


Hot works are regularly undertaken during construction and maintenance projects, and have important implications that require active risk management.

We explain how to implement a simple permit program to effectively identify and manage the added risks of hot works.

What are hot works?
Hot works include any operation that uses open flames or the local application of heat and friction. Examples include:

Welding
Soldering
Torch cutting
Grinding
Hot riveting
Heat applied to roof coverings (particularly in relation to replacement of felt coverings on flat roofs)
It is important to be aware of the full range of activities that constitute hot works, not only those that involve open flames, and ensure that proper processes are in place to manage the additional risks that accompany them.

The dangers of hot works
Hot works are frequently used during construction, demolition, renovation and maintenance. As the name suggests, they present a heightened fire risk by involving the use of heat, or the creation of sparks and other sources of ignition.

An analysis of Zurich’s claims data reveals that hot works are responsible for 10-15% of all fires in commercial and industrial properties.

The importance of a written hot work permit programme
Developing and implementing a written hot work permit programme is an essential component of effective facility risk management.

Whether they are being undertaken by your own staff or external contractors, hot works should always be authorised, monitored and documented.

It is important to note that most property insurance policies will include specific terms requiring the use of a written hot work permit programme. Having a programme in place, and periodically checking for compliance, will help to ensure you are meeting the legal, regulatory and insurance requirements that accompany hot works.

Creating and implementing your permit programme
Your hot work permit programme should be tailored to the needs of each specific location and should look to include the following fundamental aspects:

General risk assessment – risk assessments should be undertaken when introducing potentially hazardous activities such as hot works. They should be conducted by a person with the appropriate knowledge, training and experience, with awareness of the associated hazards and control measures.

Establishing designated hot work areas and requiring written hot work permits for any work outside of those areas, is the best way of achieving this.

An example hot work permit can be found in our download section.

Establishing designated areas – to establish when hot work permits are required, it is important to designate areas. An efficient way of doing this is to update your site’s general risk assessment to categorise these areas and plot them on a site map or plan.

Areas can be categorised as follows:

Designated areas – permanent places specifically designed and intended for hot works
Non-designated areas – places not designed for hot works, where a written permit is required
Prohibited areas – places where hot works should never be permitted. These can include areas featuring fast-burning construction materials, such as polystyrene, or where other combustible liquids, gases or dusts are stored or used with no reasonable means of removing them.
Managing the permit process
It is recommended that your written hot work permit programme details the following process, and that management periodically verifies that staff, contractors and sub-contractors are all following the programme:

Review of less hazardous work methods
Compile project-specific work method statements
Check worker qualifications
Work area risk assessment
Authorisation to perform hot works
Worker acknowledgement
Periodic work area inspections
Final work area inspection
Permit close out
Each element of the process is explained fully in our Risk Topics guidance note, which can be found in the download section.

Carefully review contractors’ terms
If undertaking larger projects, it is likely that the lead contractor will require you to sign a contract. It is common practice for some contracts to stipulate that insurance is taken out in the joint name of you and your contractor.

While joint name policies can have benefits for both parties, they also have important implications for how potential negligence claims are handled, in particular your insurer’s ability to recover damages from a negligent contractor who is named jointly.

If offered a contract that includes reference to joint names, it is important to seek legal advice to understand the implications concerning your rights of recovery and insurance arrangements prior to any agreement being reached
Today I will introduce for you the check lists in during bunkering on board.

Construction - Advantages and disadvantages of Globe valves


I. Check list item preparation for bunkering
1. Plug up each coaming for F.O. Tank air vent & hose connection
2. Plug up all scupper on upper deck
3. Prepare tranceiver or telephone
4. Prepare necessary tools & emergency goods at nearby hose connection: Spanner,  Waste rug,  Oil pan,  Sounding scale,   Reducer,  etc.
5. Prepere hose davit & Jacob's ladder
6. Following notice shall be hanged onto nearby bunkiering station:   Oil Transfer Procedures,  Pipe Line Diagram,  Oil Pollution Prevention Station, Bunkering Station,  Bunkering Plan  &  Inflammables
7. Prepare fire extinguisher & chemical emulsifier
8. Prepare working light in case of night time
9. Fit on pressure gauge to filling line
10. Confirm operation of remote control valve
11. Put in F.O. Additive if necessary
12. Set up bunkering line (confirm switch off F.O. transfer pump )
II. Check list during bunkering
1. Hoist a B flag
2.  Red Light in case night time
3. Confirm hose connection ( oil leak, etc.)
4. Condition of valve operation & oil level in receiving tank
5. Carry out  duty & an adequate place by bunkering station
6. Again confirm bunkering line
7. Sounding of oil in receiving tank (every 5 min.)
8. Sounding of oil in not receiving tanks (ever. 15 min.) and received tanks which valve are closed.

Hello friends! Today I will introduce you the necessary contents of the bunkering drill process on board:

Construction - Advantages and disadvantages of Globe valves

(1). Bunkering plan & sequence: disseminated, explained the content of bunker plan to all the crews.
(2). Bunkering stations: Specify duties for each engineers, officer & operators.
(3). Bunkering Checklists: disseminated, explained the content of bunkering checklist.
(4). Communications in English with Hand signals:
(5). Oil Pollution Station: Reviewed duties of each crew in Oil pollution station.
(7). Oil spill removal procedures with SOPEP: Guided for all crews about procedure to operate all equipments & material of S.O.P.E.P
(10). Familiarized to crews with safety to avoid of accident occurring while bunkering of  F.O, D.O on ship accordance with ISM/QSMS/USCG regulations/procedures by C/E educations.

Friday, February 5, 2016



Hello friends! Today I would like to introduce to you the form "Hot Work Permit" on the ship
This is the form used on the ships of the Japanese Shipowners
Please click here to download.
Thank you for visiting our blog!


Hello friends! Today I would like to introduce to you the form "High Voltage Work Permit" on the ship
This is the form used on the ships of the Japanese Shipowners
Please click here to download.
Thank you for visiting our blog!

Hello friends! Today I would like to introduce to you the form "Elevated Place Work Permit" on the ship
This is the form used on the ships of the Japanese Shipowners
Please click here to download.
Thank you for visiting our blog!
